ASRock has introduced the X870E Taichi White as one of its most feature rich AM5 motherboards, combining a premium white design with extensive connectivity, overclocking support, and compatibility with current and future Ryzen processors.
Priced at $439.99, the motherboard is aimed at enthusiasts building high end gaming or content creation systems. It uses AMD’s flagship X870E chipset and supports Ryzen 7000, Ryzen 8000, and Ryzen 9000 desktop processors through the AM5 socket.
The board also supports DDR5 memory, PCIe 5.0 graphics cards, PCIe 5.0 NVMe storage, and USB4. These features place it above mainstream B850 and standard X870 models, particularly for builders who need more expansion lanes and storage options.
The white finish is another important part of the design. Most of the heatsinks, covers, and visible components follow a silver and white theme, making the board suitable for light coloured PC builds.
X870E provides more connectivity than standard X870 boards
AMD’s X870E chipset uses two Promontory 21 chipset dies, while the standard X870 platform uses one. This gives X870E motherboards additional chipset lanes and greater flexibility for storage, networking, and other onboard devices.
Both X870E and X870 support PCIe 5.0 for graphics and NVMe storage. USB4 is also required across both chipset families, unlike older X670 and B650 motherboards where it was optional.
| Feature | ASRock X870E Taichi White |
|---|---|
| Socket | AMD AM5 |
| Chipset | AMD X870E |
| Processor support | Ryzen 7000, 8000, and 9000 families |
| Memory | Four DDR5 slots |
| Graphics support | PCIe 5.0 |
| NVMe support | PCIe 5.0 |
| USB4 | Supported |
| CPU overclocking | Supported |
| Memory overclocking | Supported |
| Price | $439.99 |
The platform supports 24 usable PCIe 5.0 lanes from compatible Ryzen processors. It can also provide additional PCIe 4.0 and PCIe 3.0 lanes through the chipset.
This makes the X870E platform better suited to systems using several high speed SSDs, expansion cards, and external devices. However, many gaming builds will not use all of this connectivity, so the higher price may be difficult to justify for less demanding configurations.
DDR5 and overclocking support target enthusiast builds
The X870E Taichi White supports four DDR5 memory modules. AMD’s platform officially supports DDR5 5600 memory, while premium motherboards may reach transfer rates above 8000 MT/s through memory overclocking.
Actual memory speeds depend on the processor, memory kit, BIOS, and the number of modules installed. Two module configurations typically provide better high speed compatibility than fully populated four slot setups.
The board also supports AMD EXPO memory profiles. This allows compatible memory kits to load tested timings and voltages through the BIOS instead of requiring every value to be configured manually.
CPU overclocking and Precision Boost Overdrive are supported as well. Ryzen 9000 processors introduced updated boost and Curve Optimizer controls, and X870E boards are designed to support those features without relying on older firmware.
The Taichi family traditionally sits near the top of ASRock’s motherboard range. This model is therefore expected to include a strong power delivery system and substantial cooling around the voltage regulator components, although the provided review section does not include the detailed power design or temperature results.
AM5 support remains one of the platform’s strongest advantages
AMD introduced the AM5 socket with its Ryzen 7000 processors. Unlike AM4, which placed pins on the processor, AM5 uses an LGA 1718 design with the contact pins inside the motherboard socket.
The change provides additional electrical connections for DDR5 memory, PCIe 5.0, and newer platform features.
AMD has committed to supporting AM5 through at least 2029. This gives buyers a clearer upgrade path than a platform expected to support only one or two processor generations.
A system built with the X870E Taichi White could therefore support later Ryzen processors through BIOS updates, provided AMD and ASRock make them compatible.
Existing AM4 compatible coolers may also work with AM5 because AMD retained similar mounting dimensions. Compatibility can still depend on the cooler and mounting hardware, so builders should verify support before installation.
The white design carries a significant premium
The X870E Taichi White is positioned as a visual and technical flagship rather than a value focused motherboard.
Its $439.99 price places it well above many B850 and standard X870 alternatives. Those cheaper boards can still provide PCIe 5.0 storage, DDR5 support, processor overclocking, and strong gaming performance.
The extra cost mainly buys a more elaborate design, additional connectivity, more expansion flexibility, and the premium Taichi branding.
For a gaming system using one graphics card and one or two SSDs, a less expensive motherboard may provide similar real world performance. Motherboards generally have little influence on gaming frame rates when the processor and memory operate at the same settings.
The X870E Taichi White makes more sense for builders who need several high speed devices, plan to upgrade the system over several years, or want a premium white motherboard that matches the rest of the build.
The available section of the review focuses primarily on the platform, chipset, and design rather than benchmark results. Final conclusions about CPU performance, gaming results, power consumption, and VRM temperatures would require the remaining review pages.
